Product parameters
Product model: SW-FC
Product material: PC /PC material
LED: Epistar 2835/Bridgelux 2835
Cable Gland: PG13.5
CRI: Ra80
Type of Protection: IP65
Warranty: 5 Years
Product Features
1. Wires, lamp holders and terminals are all certified by VDE.
2. Lock design, easy disassembly and assembly, optional PC clip or stainless steel clip, with Brackets for ceiling mounting on the back, easy to install and fix, the installation method can be suspended ceiling or suction ceiling installation, high-temperature baking paint treatment, anti-oxidation, heat dissipation performance it is good,
3. The lamp body is made of high-quality anti-ultraviolet PC material, and the lampshade is milky white, with uniform light transmission, bright and durable. Compression grade IK08, the fixture will not be damaged under pressure, high light transmittance, soft and uniform light, eye protection,
4. Built-in high-brightness LED chips, SDCM<5, through TUV-LM80, the LED light efficiency can reach 125 lumens.
5. Fashionable, complete specifications, suitable for different scenarios.
6. No noise, low temperature rise, power factor above 0.9. High efficiency, energy saving, safe and reliable
7. This tri-proof light has a long service life, exposed to sunlight and ultraviolet rays, the lamp will not turn yellow or blur within 5 years.
8. Protection level: Dustproof standard IP66, can be used in very harsh environments.
Installation Guide
1.power off before installation.
2.Connect the wire and install the material package.
3.Close the cover by clips and fix it to the brackers.
Suitable Place
Overpasses, factories, pharmaceutical factories and food factories. The kitchen. Bathroom and sauna, pedestrian corridor. Tunnels and underground factories, car parks, waiting platforms and other public outdoor areas.
Product parameters
Model |
Voltage |
Dimension(mm) |
Power |
LED Chip |
IP |
Luminous flux |
SW-FC18 |
220-240V |
600x96x79 |
18W |
SMD 2835 |
IP66 |
2200lm |
SW-FC40 |
220-240V |
1200x96x79 |
40W |
SMD 2835 |
IP66 |
4800lm |
SW-FC48 |
220-240V |
1500x96x79 |
48W |
SMD 2835 |
IP66 |
5800lm |
SW-FC55 | 220-240V | 1800x96x79 | 55W | SMD 2835 | IP66 | 6600lm |
